Panasonic AW-E800A P 3CCD Professional Color Video Camera , Price $6000.00

  Panasonic AW-E800A P  2/3-Inch 3-CCD 16:9/4:3 Industrial Color Video Camera, Convertible, for High Quality Pan/Tilt Systems

 Option cards and accessories are also available

"B" stock category item, In perfect, like new working condition, with 90 days full warranty.

Operating manual can be downloaded from HERE

Features:

  • Compact, full function box camera with flexible system capabilities using application specific, plug-in feature cards

  • Switchable between 16:9 and 4:3 aspect ratios

  • Uses three high performance and cost effective 2/3" IT CCDs

  • Excellent video quality

  • Digital Signal Processing ensures predictable and repeatable video performance

  • Video detail correction, color and contrast controls easily reached through setup menu

  • Extremely good camera matching in multiple camera systems

  • Genlockable

  • Very good low light performance

  • Compatible with large selection of standard bayonet mount lenses

  • Can be used with Panasonic pan/tilt systems which offer remote camera setup & operations plus pan/tilt and lens control

  • Built-in RS-232C interface to accommodate computer control

  • Applications include; point of view and studio broadcast, highway traffic monitoring, surveillance, web-casting, etc.





Specifications:

  • Imaging Elements: 2/3" IT type 3-CCD system (16:9 aspect ratio)
  • Pixels: Approximately 520,000
  • Scanning System: 2:1 interlaced NTSC system
  • Scanning Frequency: Horizontal: 15,734 kHz, Vertical: 59.94 Hz
  • Lens Mount: 2/3" bayonet
  • Synchronization System: Internal/external
  • Standard Sensitivity: 2,000 lux @ f/9.5
  • Minimum Sensitivity: 1.5 lux (without high sensitivity card)
  • S/N: 65 dB with DNR on
  • Horizontal Resolution: ~750 lines
  • Registration: 0.05%
  • Detail Correction: Advanced horizontal and vertical
  • White Balance: Two memory automatic correction, 3200K, 5600K, fine manual adjustment & automatic tracking white
  • Black Balance: Automatic
  • Color Bar: SMPTE color bar (setup or 7.5IRE)
  • Shutter Speed: Synchro Scan: 60.58 Hz to 15.75 kHz, Standard positions: Off, 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000 & 1/10000, ELC mode
  • Gain: AGC LOW/HIGH, 0 dB to 30 dB switchable & Night Eye
  • Iris Control: Automatic (manual with remote control)
  • Video Output: Composite 1 V p-p NTSC (BNC & 50-pin D subconnector), Y 1 V p-p (50-pin D subconnector), C (50-pin D subconnector)
  • Power Supply Voltage: 12 VDC
  • Power Consumption: Approximately 14.4 Watts
  • Operating temperature: -10 stC ~ +45 stC, (14 stF ~ 113stF)
  • External Dimensions (WxHxD): 3 5/16" x 3" x 6 1/2"

  • Weight : Approximately 1.07 kg ( 2.4 lbs.)






AW-E800AP ( Out Of Stock )$6,000.00
