In perfect working condition, like brand new, original box, operating
manual and 90 days full warranty.
With the use of multiple
(up to 8) units in a master/slave configuration, the sequential switcher shall
provide switching of up to 64 cameras. It also shall provide remote control
capability, when used with optional WV-CU300 System Controller.
The unit shall feature 2
switching modes. In Mode 1, conventional sequential camera switching is
performed, while in Mode 2, each individual camera's pause time can be
programmed, between 0 and 30 seconds, using on-screen programming. The unit
shall include an adjustable fast scanning/frame switching feature that can feed
between 2 and 12 frames per camera to a video recorder during an alarm
condition. This shall enable recording of a picture from all 8 cameras at a rate
of nearly twice a second during an alarm. The sequential switcher shall also
feature a conventional alarm mode, in which sequential switching is stopped, and
an individual camera is linked to the recorder and/or monitor. With on-screen
programming, a built-in alphanumeric titler shall allow easy superimposition of
a name or location from each camera, to simplify camera site identification. To
protect programming, the unit shall feature password entry, with an on-screen
menu for setup and programming. Another feature of the unit is its cable-loss
compensation. The unit shall be 19" rack-mountable. The power source shall
be 120VAC, 60Hz. The unit shall be UL listed.
